Product Summary

The FM3130-GTR is an integrated a real-time clock (RTC) and F-RAM nonvolatile memory. The device operates from 2.7 to 3.6V. The FM3130-GTR provides nonvolatile F-RAM which features fast write speed and unlimited endurance. This allows the memory to serve as extra RAM for the system microcontroller or conventional nonvolatile storage. This memory is truly nonvolatile rather than battery backed. The real-time clock(RTC) provides time and date information in BCD format. The FM3130-GTR can be permanently powered from extenal backup voltage source, either a battery or a capacitor. The timekeeper uses a common external 32.768 kHz crystal and provides a calibration mode that allows software adjustment.

Parametrics

FM3130-GTR absolute maximum ratings: (1)Power Supply Voltage with respect to VSS, VDD: -1.0V to +5.0V; (2)Voltage on any signal pin with respect to VSS, VIN: -1.0V to +5.0V and VIN ≤ VDD+1.0V ; (3)Backup Supply Voltage, VBAK: -1.0V to +4.5V; (4)Storage Temperature, TSTG: -55℃ to + 125℃; (5)Lead Temperature (Soldering, 10 seconds), TLEAD: 300℃; (6)Electrostatic Discharge Voltage, Human Body Model (JEDEC Std JESD22-A114-B), VESD: 4kV; Charged Device Model (JEDEC Std JESD22-C101-A), VESD: 1kV; Machine Model (JEDEC Std JESD22-A115-A), VESD: 200V; (7)Package Moisture Sensitivity Level: MSL-1.

Features

FM3130-GTR features: (1)High Integration Device Replaces Multiple Parts, Serial Nonvolatile Memory; Real-time Clock (RTC) with Alarm; Clock Output (Programmable frequency); (2)64Kb Ferroelectric Nonvolatile RAM, Internally Organized as 8Kx8; Unlimited Read/Write Endurance; 45 year Data Retention; NoDelay. Writes; (3)Fast Two-wire Serial Interface, Up to 1 MHz Maximum Bus Frequency; Supports Legacy Timing for 100 kHz & 400 kHz; RTC & F-RAM Controlled via 2-wire Interface; (4)Real-time Clock/Calendar Backup Current under 1 μA; Seconds through Centuries in BCD format; Tracks Leap Years through 2099; Uses Standard 32.768 kHz Crystal (12.5pF); Software Calibration; Supports Battery or Capacitor Backup; (5)Easy to Use Configurations, Operates from 2.7 to 3.6V; 8-pin “Green” SOIC (-G) and TDFN (-DG); Low Operating Current; Industrial Temperature -40℃ to +85℃; Underwriters Laboratory (UL) Recognized.
