Product Summary
The ADXL335BCPZ-RL is a small, thin, low power, complete 3-axis accelerometer with signal conditioned voltage outputs. The ADXL335BCPZ-RL measures acceleration with a minimum full-scale range of ±3 g. The ADXL335BCPZ-RL can measure the static acceleration of gravity in tiltsensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration. The user selects the bandwidth of the accelerometer using the CX, CY, and CZ capacitors at the XOUT, YOUT, and ZOUT pins. Bandwidths can be selected to suit the application, with a range of 0.5 Hz to 1600 Hz for X and Y axes, and a range of 0.5 Hz to 550 Hz for the Z axis.
Parametrics
ADXL335BCPZ-RL absolute maximum ratings: (1)VS: -0.3 V to +3.6 V; (2)All Other Pins: (COM - 0.3 V)to (VS + 0.3 V); (3)Output Short-Circuit Duration (Any Pin to Common): Indefinite; (4)Temperature Range (Powered): -55℃ to +125℃; (5)Temperature Range (Storage): -65℃ to +150℃; (6)Supply Current VS = 3 V: 350 μA; (7)Turn-On Time No external filter: 1 ms.
Features
ADXL335BCPZ-RL features: (1)3-axis sensing; (2)Small, low-profile package 4 mm × 4 mm × 1.45 mm LFCSP; (3)Low power - 350 μA (typical); (4)Single-supply operation 1.8 V to 3.6 V; (5)10,000 g shock survival; (6)Excellent temperature stability; (7)BW adjustment with a single capacitor per axis; (8)RoHS/WEEE lead-free compliant.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADXL335BCPZ-RL |
|
IC ACCELEROMETER 3AX 3G 16LFCSP |
Data Sheet |
|
|
||||||||||||||||
|
ADXL335BCPZ-RL7 |
|
IC ACCELEROMETER 3AXL 3G 16LFCSP |
Data Sheet |
|
|
||||||||||||||||
