Product Summary
The TCD1501DG is a CCD linear image sensor. The TCD1501DG which includes sample-and-hold circuit is a high sensitive and low dark current 5000 elements CCD image sensor. The TCD1501DG is designed for facsimile, imagescanner and OCR. The device contains a row of 5000 elements photodiodes which provide a 16 lines/mm (400DPI) across a A3 size paper. The device is operated by 5 V (pulse), and 12 V power supply.
Parametrics
TCD1501DG absolute maximum ratings: (1)Clock Pulse Voltage: -3 to 8V; (2)Shift Pulse Voltage: -3 to 8v; (3)operating temperature: -25 to 60℃; (4)storage temperature: -40 to 100℃.
Features
TCD1501DG features: (1)Number of Image Sensing Elements: 5000 elements; (2)Image Sensing Element Size: 7 fim by 7 fim on 7 fim centers; (3)Photo Sensing Region: High sensitive and low voltage dark signal pn photodiode; (4)Clock: 2 Phase (5 V); (5)Internal Circuit: S/H circuit; (6)Package: 22 pin Cerdip.
Diagrams
 |
