TLC27M7CDR

Product Summary

The TLC27M7CDR is a dual operational amplifier. The TLC27M7CDR combine a wide range of input offset voltage grades with low offset voltage drift, high input impedance, low noise, and speeds approaching that of general-purpose bipolar devices.The TLC27M7CDR uses Texas Instruments silicon-gate LinCMOS technology, which provides offset voltage stability far exceeding the stability available with conventional metal-gate processes. The extremely high input impedance, low bias currents, and high slew rates make these cost-effective devices ideal for applications which have previously been reserved for general-purpose bipolar products,but with only a fraction of the power consumption. Four offset voltage grades are available (C-suffix and I-suffix types). These advantages, in combination with good common-mode rejection and supply voltage rejection, make these devices a good choice for new state-of-the-art designs as well as for upgrading existing designs.

Parametrics

TLC27M7CDR absolute maximum ratings: (1)Supply voltage, VDD: 18 V; (2)Differential input voltage, VID: ±VDD; (3)Input voltage range, VI (any input): – 0.3 V to VDD; (4)Input current, II: ±5 mA; (5)Output current, IO (each output): ±30 mA; (6)Total current into VDD: 45 mA; (7)Total current out of GND: 45 mA; (8)Duration of short-circuit current at (or below)25℃: Unlimited; (9)Continuous total dissipation: See Dissipation Rating Table; (10)Operating free-air temperature, TA: C suffix: 0℃ to 70℃ I suffix : –40℃ to 85℃, M suffix: –55℃ to 125℃; (11)Storage temperature range: –65℃ to 150℃; (12)Case temperature for 60 seconds: FK package: 260℃; (13)Lead temperature 1,6 mm (1/16 inch)from case for 10 seconds: D or P package: 260℃; (14)Lead temperature 1,6 mm (1/16 inch)from case for 60 seconds: JG package: 300℃.

Features

TLC27M7CDR features: (1)Trimmed Offset Voltage: TLC27M7 500 mV Max at 25℃, VDD = 5 V; (2)Input Offset Voltage Drift Typically 0.1 mV/Month, Including the First 30 Days; (3)Wide Range of Supply Voltages Over Specified Temperature Ranges: 0℃ to 70℃ 3 V to 16 V, –40℃ to 85℃ 4 V to 16 V, –55℃ to 125℃ 4 V to 16 V; (4)Single-Supply Operation; (5)Common-Mode Input Voltage Range Extends Below the Negative Rail (C-Suffix, I-Suffix Types); (6)Low Noise Typically 32 nV//Hz at f = 1 kHz; (7)Low Power Typically 2.1 mW at 25℃, VDD = 5 V; (8)Output Voltage Range Includes Negative Rail; (9)High Input impedance 1012 W Typ; (10)ESD-Protection Circuitry; (11)Small-Outline Package Option Also Available in Tape and Reel; (12)Designed-In Latch-Up Immunity.
