Product Summary
The MSM82C54-2JS is a programmable universal timer designed for use in microcomputer systems. Based on silicon gate CMOS technology, the MSM82C54-2JS requires a standby current of only 10 mA (max.) when the chip is in the non-selected state. And during timer operation, the power consumption is still very low with only 10mA (max.) of current required. The MSM82C54-2JS consists of three independent counters, and can count up to a maximum of 10 MHz. The timer features six different counter modes, and binary count/BCD count functions. Count values can be set in byte or word units, and all functions are freely programmable.
Parametrics
MSM82C54-2JS absolute maximum ratings: (1)Power Supply Voltage VCC: -0.5 to +7 V; (2)Input Voltage VIN:-0.5 to VCC +0.5 V; (3)Output Voltage VOUT:-0.5 to VCC +0.5 V; (4)Storage Temperature TSTG:-55 to +150 ℃; (5)Power Dissipation PD: 0.9W.
Features
MSM82C54-2JS features: (1)Maximum operating frequency of 10 MHz (VCC=5 V); (2)High speed and low power consumption achieved by silicon gate CMOS technology; (3)Completely static operation; (4)Three independent 16-bit down-counters; (5)Status Read Back Command; (6)Six counter modes available for each counter; (7)Binary and decimal counting possible.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||
---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() MSM82C54-2JS |
![]() Other |
![]() |
![]() Data Sheet |
![]() Negotiable |
|
||||
