Product Summary

The MBR0530T1G is a surface mount schottky power rectifier. The MBR0530T1G uses the Schottky Barrier principle with a large area metal-to-silicon power diode. Ideally suited for low voltage, high frequency rectification or as free wheeling and polarity protection diodes in surface mount applications where compact size and weight are critical to the system. This package also provides an easy to work with alternative to leadless 34 package style.

Parametrics

MBR0530T1G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 30V; (2)Working Peak Reverse Voltage: 30V; (3)DC Blocking Voltage: 30V; (4)Average Rectified Forward Current (Rated VR, TL = 100℃)IF(AV): 0.5 A; (5)Non-Repetitive Peak Surge Current (Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz)IFSM: 5.5 A; (6)Storage Temperature Range Tstg: -65 to +150 ℃; (7)Operating Junction Temperature TJ:-65 to +125 ℃.

Features

MBR0530T1G features: (1)Guardring for Stress Protection; (2)Low Forward Voltage; (3)125℃ Operating Junction Temperature; (4)Epoxy Meets UL 94, V-0 @ 0.125 in; (5)Package Designed for Optimal Automated Board Assembly; (6)Pb-Free Packages are Available.


Diagrams

MBR0530T1G pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MBR0530T1G
MBR0530T1G

ON Semiconductor

Schottky (Diodes & Rectifiers) 0.5A 30V

Data Sheet

0-1: $0.23
1-25: $0.13
25-100: $0.10
100-500: $0.06
